DEL-BC400
Troughed belt conveyors
Up to 1,200 t/h, belt widths 500–1600mm, idler stations on 1m centres.
Machines, systems, and lines — built to your spec.
Six product families covering conveying, fabrication, machining, process vessels, automation, and one-off custom builds. Each ships with stamped drawings, FAT certificates, and a five-year structural warranty.
CAT-01 / Conveying
Conveyor & bulk handling
Belt, roller, screw, bucket, and pneumatic conveying for everything from clinker to cotton bales. Rated for continuous duty under Pakistani heat and dust loads.
DEL-RC120
Roller & chain conveyors
Pallet, drum, and crate handling. Gravity, motorised, or accumulating.
DEL-SC250
Screw & auger conveyors
Cement, flour, lime, fly-ash. Diameters 200–600mm, lengths to 18m.
DEL-BE800
Bucket elevators
Centrifugal-discharge for grain, fertiliser, aggregate. Lifts to 45m.
DEL-PC60
Pneumatic conveying
Dilute & dense phase systems for fine powders. Stainless or coated MS.
DEL-TR
Transfer towers & chutes
Engineered impact zones, dust suppression, walkway access platforms.
CAT-02 / Fabrication
Heavy steel fabrication
Plate prep, profile cutting, rolling, and welding under one roof. We hold IS 2062 plate stock and certified MIG/TIG/SMAW operators on every shift.
FAB-01
CNC plasma & oxy cutting
Cuts up to 6m × 2m, plate to 80mm. Nesting software for minimum scrap.
FAB-02
Plate rolling & bending
3-roll plate bending to 40mm × 3m. Press brake to 220 tonnes.
FAB-03
Certified welding
MIG, TIG, SMAW, FCAW. Weld procedures qualified to ASME IX.
FAB-04
Structural steelwork
Trusses, mezzanines, walkways, plant frames — galvanised or painted.
FAB-05
Hoppers, silos & bins
Conical and pyramidal storage. Liners in HARDOX, AR400, or stainless.
FAB-06
Process ducting
Round and rectangular ducts for dust, fume, and HVAC up to Ø2400mm.
CAT-03 / Machining
Precision metal processing
Machined parts and replacement components for plants that can't wait for European spares. Tolerances down to ±0.02mm, delivered.
MCH-01
CNC turning
Shafts to Ø600 × 3m. Live tooling, sub-spindle for one-set finishing.
MCH-02
3 & 4-axis milling
VMCs to 1500 × 800 × 700mm work envelope. Heavy material removal.
MCH-03
Grinding & honing
Cylindrical, surface, and tool grinding. Mirror finishes on hardened shafts.
MCH-04
Gear & sprocket cutting
Spur, helical, and bevel up to module 12. Hardening and case-carburising.
MCH-05
Dies & press tools
Progressive, compound, and draw dies for sheet metal stamping.
MCH-06
Reverse-engineered spares
Send the broken part — get a drawing, a quote, and a replacement.
CAT-04 / Process
Tanks, vessels & reactors
Storage and process vessels in carbon steel, stainless, or duplex. Designed to ASME VIII Div 1, hydro-tested before despatch.
VSL-01
Storage tanks
Atmospheric and low-pressure. 200L to 80,000L. SS304/316 or coated MS.
VSL-02
Mixing & blending vessels
Top, side, and bottom-entry agitators. Jacketed for heat or cooling.
VSL-03
Pressure vessels
Air receivers, autoclaves, and reactors rated to 25 bar(g).
VSL-04
Heat exchangers
Shell-and-tube and plate-type. TEMA-class fabrication and inspection.
VSL-05
Silos & bulk bins
Field-erected or shop-built. Up to 1,200m³ capacity.
VSL-06
Process skids
Pre-piped, pre-wired skids ready to drop into your plant.
CAT-05 / Automation
Production line automation
Bring an old line into the present without ripping it out. PLC retrofits, SCADA dashboards, and vision-guided handling.
AUT-01
Robotic pick & place
6-axis arms for cartoning, palletising, machine tending.
AUT-02
PLC & SCADA
Allen-Bradley, Siemens, Mitsubishi. We program, you operate.
AUT-03
Vision sorting
Camera-based reject and grading. Speeds to 600 parts per minute.
AUT-04
Packaging lines
Filler, capper, labeller, case-packer integration as one line.
AUT-05
IoT & condition monitoring
Vibration, temperature, current — alerts before bearings fail.
AUT-06
MCC & control panels
Custom panels built to UL-508A practice. Tested before shipping.
CAT-06 / Custom
If it doesn't exist yet, we engineer it.
Half our work is unique to one plant. Bring a drawing, a problem, or just a stuck operator — we'll work back from there.
CUSTOM
One-off process machinery
From hot-press laminators to rotary kilns. Concept to commissioning in 14–22 weeks typical.
RETROFIT
Plant retrofits & debottlenecking
De-rate, re-rate, replace, or re-route — without taking the plant offline for more than a planned shutdown.
